Wincomn&Alcorn Case Collection

The more exciting a project is, the more it cannot be separated from wonderful arrangement. It requires precise frame synchronization control of sound effects, graphics, mechanics, lighting, special effects and other systems. The emergence of Alcorn can perfectly achieve precise control of the entire project, allowing everything to be under control

Alcorn McBride is a manufacturer of audio, video, and control products for the theme entertainment industry. Since 1986, Alcorn's products have been applied in the core systems of famous theme parks, thousands of visitor centers, and entertainment venues around the world. The product line includes audio playback systems, video playback systems, and performance control systems.

X16X

V4X

VCore

Rideplayerx

BinloopX

Wincomn has a history of more than ten years of cooperation with this brand, and both parties have completed many project cases together. The product range covers multiple fields such as dark riding, theme projection shows, live performances, stage performances, ball screen cinemas, flying cinemas, exhibition displays, etc. Through Alcorn McBride's products, centralized management and control of audio, video, and performance equipment are achieved, ensuring precise synchronization of each link, improving the overall quality and attractiveness of the project, and presenting unparalleled audio-visual feast for customers and audiences.

(Equipment site photos)

Show&Projection

“Thus Have I Heard” Panoramic Immersive Zen Show

Wincomn was responsible for the multimedia system construction of the project, including projection system design, LED system construction, sound reinforcement system, broadcasting control system, lighting system, special effects system, ‌wire system, stage machinery system, monitoring system, main control system, strong and weak current laying system, and public broadcasting system integration. Sixteen laser projectors and other system products were used, and two Alcorn V4X were used as the overall control system for the project.

HB (Jinan) Movie Town Night Tour Projection Show

Wincomn has carried out the construction of the projection show system, responsible for the projection system, lighting system, sound amplification system, special effects system, strong and weak electricity and cable construction, as well as equipment installation and protection. The project has adopted 17 2K laser projectors, media servers, and other system equipment products. The entire system is controlled by Alcorn V16X and Alcorn Light Cu for performance and lighting control.

Immersive live action night tour performance of “Hometown”

Wincomn provided a projector with a brightness of 30000 lumens and a playback server for the projection performance part involved in the performance, to achieve lossless and uncompressed playback of the image on the screen, surrounding buildings, and walls. It was controlled by Alcorn VCore performance control equipment, and after multiple on-site adjustments by technical personnel, the projection image perfectly matched the various stage backgrounds.

Jinhua Fotang Ancient Town Night Tour Projection Show

Wincomn carried out projection design and construction work for the Wanshan Pavilion, floating bridge, and embankment of the projection show. Seven laser projectors, media servers, and other products were used, and Alcorn V16 performance control equipment was used to synchronously broadcast and control the equipment distributed on both sides of the river. After careful debugging by the designer, the projection performance was able to be played without damage, accurately, and synchronously.

“Charming Wuhu ”Linjiang Bridge Tower Projection Show

Wincomn provided services such as projection source design and production, projection system design and implementation, and precise control of video movements through Alcorn VCore performance control equipment. At the same time, laser projectors and media servers were also used in the project.

Theme Park

Universal Beijing Resort

Universal Studios is the fifth Universal Studios theme park in the world. The park contains seven theme scenic spots, including "Harry Potter's Magic World", "Transformers Base", "Jurassic World Nubula Island", "Little Yellow Man Paradise", "Kung Fu Panda World", "Hollywood", and "Future Water World". As the AV system subcontractor in the popular theme area of Universal Studios, Wincomn has provided Universal Studios with a high standard of AV system construction, as well as a large number of the latest technology AV equipment, including Alcorn's performance broadcast control system.

“720 Yuanmingyuan Park Space Shuttle ”Capsule Shape Ball Screen Cinema

720 capsule active stereoscopic ball screen system, 7 active stereoscopic projectors, Alcorn V16X performance control equipment, media server, automatic correction software, 6-degree-of-freedom motion platform, 6K120fps active stereoscopic film, uncompressed sequential frame playback, 270 degree ball screen field of view, super immersive, high-resolution, high frame rate, high color depth, uncompressed playback, precise pixel alignment, clear picture quality, true color reproduction, uncompressed media playback, ultimate audio-visual experience, active stereoscopic.

Bailuyuan Movie Park Trackless Spaceship Dark Riding "In the year 10000 AD"

The first large-scale immersive trackless dark riding project in China, designed by Wincomn, involves 12 scenes including ball screen, ring screen, flat screen, and curved screen. The control equipment adopts Alcorn V16Pro, which is used to coordinate the precise coordination between the video and audio, lighting, special effects system, machine model system, and trackless car system, integrating all elements of the entire project and seamlessly connecting them.

Huai'an Xiyouji Cultural Experience Park "Three Times Beating the White Bone Demon" Super Sensory Flying Ball Curtain Dark Riding

15 scenes, including flat screens, arc screens, ball screens, and irregular screens, were precisely controlled and managed by the Alcorn V16Pro performance control system for the overall projection system. At the same time, the project also used 30 4K laser projectors, media servers, and other products.

Huai'an Xiyouji Cultural Experience Park“Break into Gossamer Cave”Six Degrees of Freedom Virtual Reality Combination Dark Riding

18 scenes, including shape projection, phantom imaging, straight screen projection, arc screen projection, gauze screen projection, etc., were accurately synchronized and controlled for performance and timed playback using Alcorn V16Pro and Alcorn DVM8500. The project used more than 40 laser projectors, media servers, and other products.

Exhibition

Xi'an Museum Immersive Ring Screen Cinema

This cinema is a newly added immersive visual experience project in the museum. Wincomn has designed, supplied, installed, and debugged the audio and video system for the cinema. The Alcorn V16X broadcast control system is used to control the projector switch, automatic door switch at the entrance and exit, and switch control of light strip lights and lighting, achieving precise control and synchronization. 14 Keyingda projectors and lossless uncompressed media servers were also used in the project.

Beijing Planning Exhibition Center Multimedia Cinema

Wincomn has upgraded and renovated the multimedia cinema of the exhibition hall. The upgraded multimedia cinema can achieve lossless projection of 4K resolution films. The project manages and controls the entire 4K system through the Alcorn V4X performance control system, and is equipped with 4K laser projectors, lossless and uncompressed media servers, and other products.

Tang Paradise Ziyun Tower Sand Table Projection

The three-dimensional sand table is 8.55 meters long and 7.35 meters wide, restoring the pattern of Tang Chang'an City's "hundreds and thousands of households like Go games, and twelve streets like vegetable beds". It is one of the important exhibition projects of Ziyun Tower. Wincomn has created an immersive interactive projection show for it, and achieved precise synchronization of electric screens, video images, and sound tracks through the Alcorn V16 performance control system. The project also uses 12 laser projectors, media servers, and other products.

Shaanbei Folk Song Museum Ball Screen Cinema

On the basis of traditional dome screens, the Shaanbei Folk Song Museum has expanded the left and right sides as well as the front of the audience stand, creating a super immersive experience beyond ordinary dome screens. Wincomn has selected 22 laser projectors for the cinema to complete the projection of the dome screen and the ground, and controlled the precise synchronization of the entire projection system through the Alcorn V16Pro entertainment broadcast control system. At the same time, the cinema also adopts products such as automatic correction system and media server.

Changchun City Planning Multimedia Sand Table Projection

The multimedia sand table hall is a hemispherical three-dimensional space, with a large intelligent urban sand table on the ground, a hyperbolic curved screen around it, and a sky linked projection on top. The total area of the sand table is about 1100 square meters. The entire projection system controls the performance control system, lighting system, and audio system through products such as Alcorn V16 Pro and Alcorn Light Cure, ensuring that the projection images, audio, and on-site lighting are played in an orderly manner through time codes. Multiple 30000 lumens projectors and 4K/8K lossless media players were also used in the project.
